| Print Characteristics |
|
| Print Method |
Direct Thermal |
| Print Speed |
Up to 150 mm/s |
| Print Resolution |
203 dpi |
| Print Width |
12 / 48 / 54 / 72/ 80 mm |
| Sensor |
Paper End, Cover Open, Near End, Black Mark, Gap Sensor |
| Media Characteristics |
|
| Media Type |
Ticket, Label (Gap, Black Mark) |
| Media Width |
20 / 58 / 60 / 80 / 83 mm |
| Media Roll Diameter |
130 / 150 mm |
| Media Thickness |
0.05 ~ 0.20 mm |
| Supply Method |
Easy Paper Loading |
| Physical Characteristics |
|
| Dimensions (W x L x H) |
Media Roll Diameter Φ130: 130 x 181 x 123 mm Media Roll Diameter Φ150: 130 x 188 x 130 mm |
| Weight |
780 g |
| Electrical |
100-240 V AV, 50/60 Hz |
| Lever Direction |
Right |
| Mount Direction |
Horizontal |
| Performance Characteristics |
|
| NV Image Memory |
256 Kbytes (Mono) |
| Receive Buffer |
64 Kbytes |
| User Define Buffer |
12 Kbytes |
| Interface |
USB V2.0 FS+ Serial |
| Connector Type |
Power: DC-Jack or 2P Connector USB: USB B type or 4P Connector Serial: 9P Male or 5P Connector |
| Environment Characteristics |
|
| Temperature |
Operating: -20 ~ 60 ℃ (-4 ~ 140 ℉) ※ Optimal printing performances and maximum reliability will be obtained between 0 and 40 °C Storage: -20 ~ 60 ℃ (-4 ~ 140 ℉) |
| Humidity |
Operating: 10 ~ 95 % (non-condensing) Storage: 10 ~ 95 % (non-condensing) excluding paper |
| Software |
|
| Emulation |
BXL / POS |
| Driver / Utility |
Windows Driver, OPOS Driver, Linux / Mac CUPS Driver, Utility Program |
| Developer Tools |
Developer Tools Android SDK, Windows SDK, Linux SDK, Web Print SDK (Windows, Android) |
| Fonts / Graphics / Symbologies |
|
| Character Size |
Font A: 12 x 24 Font B: 9 x 17 Font C: 9 x 24 KOR, CHN, JPN: 24 x 24 |
| Characters Per Line |
Print width 12 mm : Font A: 8 Font B, C: 10, KOR, CHN, JPN: 4 Print width 48 mm : Font A: 32 Font B, C: 42, KOR, CHN, JPN: 16 Print width 54 mm : Font A: 36 Font B, C: 48, KOR, CHN, JPN: 18 Print width 72 mm : Font A: 48 Font B, C: 64, KOR, CHN, JPN: 24 |
| Character Sets |
Alphanumeric: 95 Extended Graphics: 128 x 35 page International: 32 |
| Graphics |
Supporting user-defined fonts, graphics, formats and logos |
| Barcode Symbologies |
1D: Coda Bar, Code 39, Code 93, Code 128, EAN-8, EAN-13, ITF, UPC-A, UPC-E 2D: Data Matrix, GS1-128, GS1 DataBar Stacked / Omnidirectional / Truncated / Limited / Expanded, PDF417, QR code |
| Accessories |
|
| Optional |
SMPS (DC Jack), SMPS (2P Connector), Male to Male type Serial Cable, 5P to Male type Serial Cable, USB A-B Cable 1.8 m, Power Cord |
| Option |
|
| Bezel |
Non-Bezel / Standard-Bezel (4 types) |
