| Print Method |
Direct Thermal |
| Print Speed |
Up to 5 ips (127 mm/sec - Label) Up to 4 ips (102 mm/sec - Linerless) 12.5% pattern |
| Print Resolution |
203 dpi |
| Print Width |
Up to 72 mm |
| Sensor |
Gap Black mark Paper cover open |
| Media Type |
Label, Linerless (Optional) |
| Media Width |
80 mm / 58 mm (Optional) |
| Media Roll Diameter |
Up to 49 mm |
| Media Thickness |
0.07 ~ 0.15 mm |
| Media Inner Core |
Min.19mm |
| Supply Method |
Easy Paper Loading |
| Dimensions (WxLxD) |
105.0 x 126.0 x 58.0 mm (4.14 x 4.97 x 2.29 inch) |
| Weight |
Including battery: 385 g (0.85 Ibs.) Paper : 133 g (0.29 lbs.) |
| Battery |
7.4 V Li-ion, 2,600 mAh, Rechargeable Charging time: Up to 4.0 hrs |
| Memory |
128 MB SDRAM, 256 MB Flash 256 MB SDRAM, 512 MB Flash (Optional) |
| Interface Options |
Standard: USB V2.0 HS + Serial Optional: USB V2.0 HS + Serial + Bluetooth¹ / WLAN²--- Bluetooth¹: V4.1 Classic & LE WLAN²: 802.11a/b/g/n (Infrastructure, Ad-hoc, Wi-Fi Direct, SoftAP) - WEP40/104, WPA1/2(PSK, EAP) * Easy Bluetooth Paring™ via NFC |
| Temperature |
Operating: -15 ~ 50℃ (5 ~ 122℉) Storage: -30 ~ 70℃ (-22 ~ 158℉) |
| Humidity |
Operating: 10 ~ 80% RH |
| Water and Dust |
IP54 |
| Drop Rate |
1.8 m (6 ft.) |
| Emulation |
SLCS, BPL-Z™, BPL-C™ |
| Driver / Utility |
Windows Driver (Euro Plus/Seagull), Linux / Mac CUPS Driver, Virtual COM USB Driver, Utility Program, LabelArtist™Mobile(Android,iOS), LabelArtist™-II, Bartender UL, OPOS Driver, Web Driver |
| SDK / Plugin |
iOS SDK, Android SDK, Windows SDK, Linux SDK, Chrome SDK |
| Fonts |
• 10 SLCS Resident Bitmap Fonts • One SLCS Resident Scalable Font • 16 BPL-Z™ Resident Bitmap Fonts • One BPL-Z™ Resident Scalable Font • 7 BPL-C™ Resident Bitmap Fonts • 23 Code Page • Unicode supported (UTF-8, UTF-16LE, UTF-16BE) |
| Graphics |
Supporting user-defined fonts, graphics, formats, layouts and logos |
| Barcode |
1D: Codabar, Code 11, Code 39, Code 93, Code 128, EAN-13, EAN-8, Industrial 2-of-5, Interleaved 2-of-5, Logmars, MSI, Plessey, Postnet, GS1 DataBar (RSS-14), Standard 2-of-5, UPC/EAN extensions, UPC-A, UPC-E, IMB 2D: Aztec, Codablock, Code 49, Data Matrix, MaxiCode, MicroPDF417, PDF417, QR code, TLC 39 |
| Standard Accessories |
Belt Clip, Battery Pack, Battery Charger, Power Cord |
| Optional Accessories |
Belt Strap, Shoulder Strap, Single Battery Cradle, Quad Battery Charger, Cigarette Lighter Charger, Serial/USB Cable, Cleaning Pen |
