| SKU | citcts4000 |
|---|---|
| Proizvođač | Citizen |
| Klasa štampača | POS printer |
| Tip štampača | desktop |
| Rok Isporuke | 45 dana |
|
Printing method |
|
|
Line thermal dot printing |
|
|
|
|
|
|
|
|
|
Printing width |
|
|
112mm paper: 104mm/832 dots, 82.5mm paper: 82.5mm/660 dots, |
|
|||||||
|
|
|
|
80mm paper: 72mm/ 576 dots |
|
|
|
|
|
|
|
|
|
Dot pitch |
|
|
8 x 8 dots/mm (203 dpi x 203 dpi) |
|
|
|
|
|
|
||
|
Printing speed |
|
|
Max. 150mm/sec (35.4 lines/sec) |
|
|
|
|
|
|
||
|
Number of columns |
112mm paper: Font A – 69 columns / Font B – 92 columns |
/ Font C – 104 columns |
|
||||||||
|
|
|
|
82.5mm paper: Font A – 55 columns / Font B - 73 columns / Font C – 82 columns |
|
|||||||
|
|
|
|
80mm paper: Font A - 48 columns, Font B - 64 columns / Font C - 72 columns |
|
|||||||
|
Character size (WxH) |
Font A: 1.25 x 3.00mm (12 x 24 dots) |
|
|
|
|
|
|||||
|
|
|
|
Font B: 0.88 x 2.13mm (9 x 17 dots) |
|
|
|
|
|
|
||
|
|
|
|
Font C: 0.88 x 2.00mm (8 x 16 dots) |
|
|
|
|
|
|
||
|
Character table |
|
|
Code page 437, 850, 852, 857, 858, 860, 863, 864, 865, 866, |
|
|
||||||
|
|
|
|
Katakana, WPC1252 , Thai code 18 |
|
|
|
|
|
|
||
|
Barcode type |
|
|
UPC-A/E, JAN (EAN)-13/8, ITF, Code 39, Code 128, CODABAR, Code 93, PDF-417 |
|
|||||||
|
|
|
|
(Label type only) |
|
|
|
|
|
|
|
|
|
Line spacing |
|
|
4.23mm (1/6 inch); can be set by command. |
|
|
|
|
||||
|
Paper |
|
|
Roll paper: 112 / 82.5 / 80mm x Ø102mm (max.) Thickness: 0.065 – 0.150mm, Label paper: |
||||||||
|
|
|
|
112mm x Ø102mm (max.) Thickness: 0.150mm (max), Label width: 108mm (max.), |
||||||||
|
|
|
|
Label length: 25mm/pc (min.) |
|
|
|
|
|
|
|
|
|
Interface |
|
|
Parallel (IEEE 1284) & USB, Serial (RS-232C) & USB |
|
|
|
|
||||
|
Input buffer |
|
|
4K bytes / 45 bytes |
|
|
|
|
|
|
|
|
|
NV user memory |
|
|
384K bytes |
|
|
|
|
|
|
|
|
|
Drawer kick-out |
|
|
2 Drawers |
|
|
|
|
|
|
|
|
|
Power supply |
|
|
Input: AC 100-240V, 50/60 Hz, 150VA |
Output: DC24V, 2A |
|
|
|||||
|
|
|
|
DC 24V±7% (DC power supply type) |
|
|
|
|
|
|
||
|
Weight |
|
|
AC power type; 2.1kg / DCP power type: 1.9kg |
|
|
|
|
||||
|
Dimensions (W x D x H) |
177 x 213 x 147mm |
|
|
|
|
|
|
|
|||
|
Operating environment |
5~40°C, 10~90% RH (No condensation) |
|
|
|
|
||||||
|
Storage environment |
-20~60°C, 10~90% RH (No condensation) |
|
|
|
|
||||||
|
Reliability |
|
|
Main unit: 20,000,000 lines, Thermal head: 100,000,000 pulses or 100km |
|
|||||||
|
|
|
|
Auto cutter: 1,000,000 cuts |
|
|
|
|
|
|
|
|
|
EMC and safety standards |
UL, C-UL, FCC Class A, TUV-GS, CE marking, CCC |
|
|
|
|
||||||
| Opšti uslovi prodaje | |||||
|---|---|---|---|---|---|
| Kupovinom ovog proizvoda dobijate samo proizvod onako kako je naznačeno u ponudi-profakturi | |||||
| Dodatna podešavanja proizvoda po secifičnim potrebma nisu uključena u cenu osim ako to nije navedeno u ponudi. | |||||
| Integracija u postoljeće sisteme nije uključena u cenu proizvoda osim ako to nije navedeno u ponudi | |||||
| Garantni rok za sve uređaje je 12 meseci ukoliko nije navedeno drugačije. |
